Overview
Skull, Facial Bones and Sinuses is built on lines and ridges. The skull holds 22 bones, 8 cranial and 14 facial, and positioning starts from lines drawn from facial landmarks to the ear: the orbitomeatal line (OML) for the PA, Caldwell and Towne, the mentomeatal line for the Waters, the lips-meatal line for the modified Waters. The OML and IOML sit 7 to 8 degrees apart, so swapping lines moves the tube angle by that much: the AP axial Towne runs 30 degrees caudad to the OML or 37 to the IOML.
The PA, Caldwell and Waters views are judged by where the dense petrous ridges land. A straight PA at 0 degrees fills the orbits with them; the 15 degree Caldwell drops them to the lower third of the orbits; a 25 to 30 degree PA axial puts them at the infraorbital margin; the Waters, with the OML at 37 degrees, clears them below the maxillary sinuses. The modified Waters (OML at 55 degrees) leaves the ridges in the lower half of the sinuses but sets the orbital floors perpendicular to the receptor, which is why Bontrager and Merrill's both name it for blowout fractures. On a correct Towne, the dorsum sellae sits inside the shadow of the foramen magnum.
Sinus rules: upright position, horizontal beam, no tube angle on the routine projections. The horizontal beam is what catches an air-fluid level, so a patient who cannot sit up is still shot with one, and a patient moved from recumbent to erect waits at least 5 minutes before exposure. The lateral is the routine projection the textbooks credit with all four sinus groups at once.
The mandible axiolateral oblique picks its target by rotation: 0 degrees for the ramus, 10 to 15 for a general survey, 30 for the body, 45 for the mentum. TMJs are imaged closed and open mouth, never open on a suspected fracture. Procedures supplies 66 of the 200 scored ARRT questions to 28 February 2027, and 72 from 1 March 2027.
